Please note that the Behind-The-Prop™ Starter must only be connected to a 12 Volt, D.C. power source.
Battery Tray Dimensions:
| Inside Dimensions |
|---|
| Width | Length | Height | Units |
| 6-1/4 | 12-1/2 | Unlimited | Inches |
|
|
Overall Dimensions:
| Fully Opened, 90° |
|---|
| Width | Length | Height | Units |
| 18-1/4 | 20-1/4 | 19 | Inches |
|
|
Overall Dimensions:
| Fully Folded |
|---|
| Width | Length | Height | Units |
| 18-1/4 | 23-9/32 | 4-11/16 | Inches |
|
|
Angular Adjustment Range:
| Angle Scale Reading, 1° Resolution |
|---|
| Vertical | - | Max | Units |
| 90 | - | 67 | Degrees |
|
|
Spinner Height Adjustment Range:
| No Tilt, Vertical, Measured From Center of DynaTron Insert to Ground |
|---|
| Min | - | Max | Units |
| 8-1/2 | - | 15-1/2 | Inches |
|
|
Spinner Height Adjustment Range:
| Angle Set to 72°, Measured from Center of DynaTron Insert to Ground |
|---|
| Min | - | Max | Units |
| 4-7/8 | - | 11-1/2 | Inches |
|
|
Weight:
| No Battery or Starter Motor Installed |
|---|
| Min | Typical | Max | Units |
| N/A | 9,6 | N/A | pounds,ounces |
|
|
Electrical:
| Relay Contact Current |
|---|
| Max Make | - | Max Break | Units |
| 240 | - | 80 | Amps |
|
|
